Microservo motor control using LDR
Hello friends in this blog you are learn How to control a micro servomotor using LDR
Components required
1. Arduino uno
2. Micro servomotor
3. LDR (Light dependent resistor)
4. 1k Ohm resistor
5. Few Male to male jumper wires
Circuit diagram
Program code
//@BigEdx youtube channel
#include<Servo.h>
Servo servomotor;
void setup() {
servomotor.attach(3); //servomotor connect to arduino ~ PWM pin 3
}
void loop() {
// Analog input from LDR to A1 pin:
int value= analogRead(A1);
if(value<300){
servomotor.write(180);
}
//servmotor rotate 180
else{
servomotor.write(0);
}
//servmotor rotate 0
}
Program view
Program explanation
Micro servomotor signal wire connected to Arduino PWM pin ~3
and LDR analog input wire connected to Arduino A1 pin
When Light intensity focus increases on ldr then servomotor rotate 180 degree and light intensity not focusing on LDR then servomotor rotate 0 at their home position
If you facing any problem you are free to contact me
